Photograph
Pulverizer Mill
A male employee, Don Ferch, attends to a pulverizer mill. This unit was purchased by the Foster Wheeler Energy Corporation and used by the Public Service of Indiana Unit number 1. This specific pulverizer mill was a later component of a coal pulverizer. Original Falk caption reads, "This is a customer's standard unit. 537 HP with input at 870 RPM, ratio 27.83:1, output speed 31.26. Service factor 2.0, double ratio with 4.062 spiral bevels as first reduction, single helicals as second reduction (6.85:1 ratio). Anti-friction bearings throughout. Low speed thrust bearing is a special spherical roller SKF294/630. ALl other bearings are tapered roller bearings. Pressure lube system and cooling, oil filtering, oil metering is provided with each unit. Turning gear arrangement is provided for each set of units (such as six). Photos show hydraulic pump and motor system for testing the unit at full speed but no load. Six units are on this order." |
Image ID: | 50693 |
---|---|
Creation Date: | 08 20 1976 |
Creator Name: | Unknown |
City: | Milwaukee |
County: | Milwaukee |
State: | Wisconsin |
Collection Name: | Falk Corporation photographs, 1954-1994 |
Genre: | Photograph |
Original Format Type: | negative, original |
Original Format Number: | PH 6524, EG 48389 |
Original Dimensions: | 10 x 8 inches |
Original Falk negative number: EG 48389. Negative originally filed under the Industry-Pulverizer Mills category at the Falk Corporation. Falk caption reads, "For similar photo see EG 48400." |
Factories |
Machinery |
Machinery industry |
Metal industry |
Metal trade |
Men |
This image is issued by the Wisconsin Historical Society. Use of the image requires written permission from the staff of the Collections Division. It may not be sold or redistributed, copied or distributed as a photograph, electronic file, or any other media. The image should not be significantly altered through conventional or electronic means. Images altered beyond standard cropping and resizing require further negotiation with a staff member. The user is responsible for all issues of copyright. Please Credit: Wisconsin Historical Society. |
Location: | Wisconsin Historical Society Archives, 4th Floor, Madison, Wisconsin |
---|
